experimental pot design

Joined
Jan 19, 2007
Messages
4,832
An idea of mine for a self cooling pot I had been tossing around for quite a few years but never got around to trying...
Based on an ancient technology used to preserve food but with Cp application modifications

A dear friend sent a nice cobra so what better time to try :)

Pictures are self explanatory I believe
Porosity of the terra cotta is critical of course.


z1


z2


z3


z4


z5


z6


z7


z8


z9


z10


no moving parts and nothing to fail = elegant imho


Relevant variables:
RH 46%
Dewpoint 63%
Maximum ambient surface temperature detected by FLIR thermography 93.7f
Pot 78.9f
DeltaT 14.8f

thanks for looking, :beer:

I did not adjust for thermal emissivity or reflectivity so take the temps with a grain of salt.

Last edited:
Joined
Jan 19, 2007
Messages
4,832
yes,

But to pick the fly dung out of the pepper..... infrared thermography doesn't measure temperature per say but emitted radiation.... has to do with emissivity of the object etc etc.
If emissivity is "1" then these two line up fairly well, flat black for example has a emissivity of close to one, whereas chrome is very low
The camera would see the chrome object as being colder than the black, when both could have the same surface temperature.
An object's absorbtivity will also equal it's emissivity, and there are also variables such as reflectivity and transmissivity....

quiz in the morning :)


but yes, the actual air temperature is in the low 90's

Last edited:
Joined
Jun 24, 2012
Messages
1,215
Location
Mansfield UK
More fly dung.

I see that the medium temperature is higher than the outside of that pot.
What temperature is the medium at AND how does that compare to a standard Darlingtonia pot or a Darlingtonia in a flooded Sphagnum tray.

Sometimes one can just wonder why one got up in a morning

Joined
Jan 19, 2007
Messages
4,832
good question, just had checked that using a metal probe, the media at root depth is currently about 12 degrees cooler than actual air temp....

have no idea about a comparison, but all things being equal, if no means of cooling/heating is taking place the temperature of an object should equal ambient under isothermal conditions

errr at least I think, not my area of expertise though :)
maybe someone with more knowledge can chime in on that

Last edited:
Joined
Feb 22, 2014
Messages
1,500
Location
Oregon
As I understand it infrared thermometers generally default to 0.95 emissivity, which is pretty close to the value for most materials. I remember looking up values the first time I tried starting seeds to monitor soil temperature.

How much did that thermal camera set you back?

Joined
Jan 19, 2007
Messages
4,832
flat black grill paint and 3m electrical tape are close to 0.95, whereas chrome can be significantly less.
I demonstrate this to my students with an old clothes iron that I have painted one half flat black and left the other half normal stainless steel.

I have three, that particular camera is a cheapie (relatively speaking) at 2.5k, I have a nice FLIR that was 18k

Last edited:
Joined
Jan 19, 2007
Messages
4,832
I honestly didn't remember those but I bet they are probably what planted the seed in my head!!!

I must give credit where credit is due :)

Joined
Jan 19, 2007
Messages
4,832
worst case scenario all out torture test, put in direct sun in back of pickup truck bed that has a flat black bedliner (the horror!!)

peak ambient surface temp 153.7f
pot temp 88.5f, with some areas as low as 71.6

z12


hehehehe, guess I better move it before I kill it

Last edited:

vraev

Carnivorous plant enthusiast
Admin
Joined
Aug 14, 2006
Messages
2,815
Location
Ontario, Canada
Thats awesome B. I need to pot up my degrading cobra in a pot like that and plop it outside. :)


Jcal

Decumbent Fanatic
Joined
Mar 8, 2012
Messages
1,247
Location
Zone 7a
Reminds me of slack potting. Thanks for the details. Nice results

Joined
Jun 6, 2008
Messages
3,014
Location
SF, CA
Butch, I am a bit concerned that you have insufficient silicone adhesive on that pot. There's still some in the tube; I feel sure of that, heh, heh, heh. It reminded me a bit of the Drosophyllum pot that Adrian Slack had recommended, back in the 1980s . . .





I later adapted it to grow some Helis outside, in very un-tepui like Southern CA. Wet moss replaced the sand between pots . . .
